| 订货号 |
包装规格 |
| Sizes |
| 465-587-05 |
150mm x 150mm |
| 365-144-58 |
300mm x 300mm |
| 839-469-87 |
332mm x 345mm |
| 949-310-17 |
600mm x 600mm |
| Coil |
| 312-563-88 |
600mm x 0.5m |
| 070-482-34 |
600mm x 1m |
| 810-295-61 |
600mm x 2m |
| 286-950-55 |
600mm x 5m |
| 013-705-06 |
600mm x 10m |
| 573-165-74 |
600mm x 20m |
半岛bd体育手机客户端 参数
| Coil Width[卷材宽度] |
600mm |
| Colour[颜色] |
Opaque Grey |
| Structure[结构] |
Biaxially Oriented |
| Thickness[厚度] |
0.35mm |
| Chemical Resistance(耐化学性) |
| Acids - concentrated |
Good-Poor |
| Acids - dilute |
Good |
| Alcohols |
Good |
| Alkalis |
Poor |
| Aromatic hydrocarbons |
Good-Fair |
| Greases and Oils |
Good |
| Halogenated Hydrocarbons |
Good-Poor |
| Halogens |
Fair-Poor |
| Ketones |
Good-Fair |
| Electrical Properties(电气特性) |
| Dielectric constant @1MHz |
3 |
| Dielectric strength ( kV mm?? ) |
17.0 |
| Dissipation factor @ 1kHz |
0.0020 |
| Surface resistivity ( Ohm/sq ) |
10?? |
| Volume resistivity ( Ohmcm ) |
>10?? |
| Thermal Properties(热性能) |
| Coefficient of thermal expansion ( x10?? K?? ) |
20.000 - 80.000 |
| Heat-deflection temperature - 0.45MPa ( C ) |
115 |
| Heat-deflection temperature - 1.8MPa ( C ) |
80.0 |
| Lower working temperature ( C ) |
-40 - -60 |
| Specific heat ( J K?? kg?? ) |
1200.0 - 1350.0 |
| Thermal conductivity ( W m?? K?? ) |
0.15 - 0.40 @23℃ |
| Upper working temperature ( C ) |
115 - 170 |
| Physical Properties(物理性质) |
| Density ( g cm?? ) |
1.300 - 1.400 |
| Flammability |
HB |
| Limiting oxygen index ( % ) |
21 |
| Radiation resistance |
Good |
| Refractive index |
1.580-1.640 |
| Resistance to Ultra-violet |
Fair |
| Water absorption - equilibrium ( % ) |
< 0.70 |
| Water absorption - over 24 hours ( % ) |
0.100 |
| Mechanical Properties(机械性能) |
| Coefficient of friction |
0.20 - 0.40 |
| Hardness - Rockwell |
M94-101 |
| Izod impact strength ( J m?? ) |
13.0 - - 35.0 |
| Poisson's ratio |
0.370 - 0.440 |
| Tensile modulus ( GPa ) |
2.00 - 4.00 |
| Tensile strength ( MPa ) |
80.00 , for biax film 190-260 |
其他参数
公差
| 直径 |
<100mm |
±1mm |
| ≥100mm |
+2% / -1% |
| 厚度 |
|
±20% |
| 长度 1 |
<100mm |
±1mm |
| ≥100mm |
+2% / -1% |
| 长度 2 |
<100mm |
±1mm |
| ≥100mm |
+2% / -1% |
|
|
