半岛bd体育手机客户端 介绍
| 订货号 |
包装规格 |
| Sizes |
| 430-198-72 |
150mm x 150mm |
| 707-500-32 |
300mm x 300mm |
| 886-350-99 |
600mm x 600mm |
| Coil |
| 909-840-33 |
600mm x 1m |
| 842-945-80 |
600mm x 2m |
| 929-544-36 |
600mm x 5m |
| 524-450-22 |
600mm x 10m |
半岛bd体育手机客户端 参数
| Category[类别] |
Green Production |
| Coil Width[卷材宽度] |
600mm |
| Thickness[厚度] |
0.5mm |
| Mechanical Properties(机械性能) |
| Abrasive resistance - ASTM D1044 ( mg/1000 cycles ) |
65 |
| Hardness - Rockwell |
34-125 |
| Izod impact strength ( J m?? ) |
100.0 - 450.0 |
| Tensile modulus ( GPa ) |
1.00 - 4.00 |
| Tensile strength ( MPa ) |
12.00 - 110.00 |
| Chemical Resistance(耐化学性) |
| Acids - concentrated |
Poor |
| Acids - dilute |
Good-Poor |
| Alcohols |
Fair-Poor |
| Alkalis |
Poor |
| Aromatic hydrocarbons |
Good-Poor |
| Greases and Oils |
Good |
| Halogenated Hydrocarbons |
Good-Poor |
| Halogens |
Poor |
| Ketones |
Poor |
| Physical Properties(物理性质) |
| Density ( g cm?? ) |
1.300 |
| Flammability |
HB |
| Limiting oxygen index ( % ) |
19 |
| Radiation resistance |
Fair |
| Refractive index |
1.490 |
| Resistance to Ultra-violet |
Fair |
| Water absorption - over 24 hours ( % ) |
1.900 - 7.000 |
| Thermal Properties(热性能) |
| Coefficient of thermal expansion ( x10?? K?? ) |
80.000 - 180.000 |
| Heat-deflection temperature - 0.45MPa ( C ) |
52 - 105 |
| Heat-deflection temperature - 1.8MPa ( C ) |
48.0 - 86.0 |
| Lower working temperature ( C ) |
-20 |
| Specific heat ( J K?? kg?? ) |
1200.0 - 1900.0 |
| Thermal conductivity ( W m?? K?? ) |
0.16 - 0.36 @23℃ |
| Upper working temperature ( C ) |
55 - 95 |
| Electrical Properties(电气特性) |
| Dielectric constant @1MHz |
~ 5 |
| Dielectric strength ( kV mm?? ) |
11.0 |
| Dissipation factor @ 1kHz |
0.0600 |
| Volume resistivity ( Ohmcm ) |
5x10?? |
其他参数
公差
| 直径 |
<100mm |
±1mm |
| ≥100mm |
+2% / -1% |
| 厚度 |
|
±20% |
| 长度 1 |
<100mm |
±1mm |
| ≥100mm |
+2% / -1% |
| 长度 2 |
<100mm |
±1mm |
| ≥100mm |
+2% / -1% |
|
|
